Product Series:Air Bearing

Product Number:DQFX-062100/1.2A1-WM

It is applied to processing such as perforation, rounding, cutting, edge repair, grinding, etc. of workpieces such as glass, acrylic, composite material, ceramic, sapphire, and non-ferrous metal. This application covers areas such as consumer electronics (mobile phones, smart wearables, tablets, computers, etc.) and automobiles.

1、High efficiency

high power and high torque single-winding and double-winding asynchronous motor and synchronous motor are available, with the spindle of grease lubrication and oil air lubrication, which can ensure the efficient processing of products.


2、High stability

full structural simulation optimization and comprehensive test; and a total of 100,000 spindles are used andverified by our customers, with stable and reliable product quality and good market reputation.


3、Super long durability and high stability broach mechanism

The tool replacement life of the exclusively patented Haozhi broach mechanism is ≥10million times, the force reduction value is less than 10% during the use process, and the spindle vibration is 30% lower than that of the traditional disc spring broach mechanism, and the vibration fluctuation value during the life cycle of the broach mechanism is ≤10. %to be.


4、High rigidity, low vibration

With a reasonable shaft system design and a design consisting of an excellent rotor and brooch mechanism, the main shaft has features such as high strength,low vibration, and high power.


5、High precision

Generalmachiningrotationspeed reaches 80% of the maximum rotation speed, heat extension is stable to less than 0.03mm (partial products are stable to less than 0.02mm), heat extension fluctuation is ≤0.002mm, hole jump is≤1μm, positive Dynamic precision is≤2μm, dynamic precision is ≤8μm.
